017Series
Large Diaphragm Condenser Microphone
FET
$2299
TUBE
$4599
Open and graceful top-end, warm midrange, full and balanced low-end
Custom large capsule designed and machined in-house
Proprietary toroidal transformer imparts color and depth
Hear the 017 Series
More in Soyuz Listening Library
Nigel Godrich
Producer of Radiohead, Paul McCartney, and Beck
I put it [the 017] up against my best tube U47, which is my all time favourite mic... What was crazy was just how close sounding your mic was to the best mic in the world... I would definitely say that I would use this mic over many others in practical use.
LARGER
THAN LIFE
THAN LIFE
The classic sound of the 017 was previously considered impossible to achieve with new microphones. Engineers routinely spent small fortunes on vintage condensers and fought to keep them operational as they aged as new models – and even reissues – were often not imbued with the same desired characteristics despite their hefty price tags. This is not surprising: manufacturing techniques have changed, why wouldn’t the results?
With its open top-end, smooth mid-range, powerful – yet balanced – low-end, and remarkably robust build quality, the 017 is destined to be the future benchmark of that elusive mixture of accuracy and sonic flattery that has sent vintage prices soaring.
With its open top-end, smooth mid-range, powerful – yet balanced – low-end, and remarkably robust build quality, the 017 is destined to be the future benchmark of that elusive mixture of accuracy and sonic flattery that has sent vintage prices soaring.
THE TSAR
OF MICS
The classic sound of the 017 was previously considered impossible to achieve with new microphones. Engineers routinely spent small fortunes on vintage condensers and fought to keep them operational as they aged as new models – and even reissues – were often not imbued with the same desired characteristics despite their hefty price tags.
This is not surprising: manufacturing techniques have changed, why wouldn’t the results? With its open top-end, smooth mid-range, powerful – yet balanced – low-end, and remarkably robust build quality, the 017 is destined to be the future benchmark of that elusive mixture of accuracy and sonic flattery that has sent vintage prices soaring.
This is not surprising: manufacturing techniques have changed, why wouldn’t the results? With its open top-end, smooth mid-range, powerful – yet balanced – low-end, and remarkably robust build quality, the 017 is destined to be the future benchmark of that elusive mixture of accuracy and sonic flattery that has sent vintage prices soaring.
TRY SOYUZ
IN YOUR OWN STUDIO
TUBE OR FET
The 017 Series is comprised of FET (field effect transistor) and tube (valve) powered models. Though the FET and Tube models are similar – the two share identical capsules, form factors, and sonic signatures – there are subtle differences between them.
The 017 FET captures transients with a somewhat faster, tighter response; the 017 TUBE’s smoother, rounded top-end is perfect for sources requiring warmth with slightly more coloration.
The 017 FET captures transients with a somewhat faster, tighter response; the 017 TUBE’s smoother, rounded top-end is perfect for sources requiring warmth with slightly more coloration.
017FET
The green-badged 017 FET
comes in a wooden case
with a custom, hand-machined shock mount.
comes in a wooden case
with a custom, hand-machined shock mount.
017TUBE
The blue-badged 017 TUBE comes in a wooden case
with a custom, hand-machined shock mount, special 6-pin cable, power supply, and extra 6ZH1P pentode tube.
with a custom, hand-machined shock mount, special 6-pin cable, power supply, and extra 6ZH1P pentode tube.
A HERITAGE OF INNOVATION, A TRADITION OF EXCELLENCE
The engineers at Soyuz have spent decades studying, servicing, and building classic microphones; Soyuz’ machinists are the best in the world.
This unique pool of knowledge, craft and skill – combined with the ears of numerous musicians, producers and audio engineers – has culminated in the creation of the 017 Series’ custom S17 capsule.
Featuring a gold-sputtered, hand-tuned 34mm diaphragm, the S17 is loosely based on the original K67 capsule developed in 1960.
Far from creating another clone of a classic, however, Soyuz has further developed the design, modifying its assembly and tuning. The result, when paired with Soyuz’s original schematic, is unique – and uniquely musical.
This unique pool of knowledge, craft and skill – combined with the ears of numerous musicians, producers and audio engineers – has culminated in the creation of the 017 Series’ custom S17 capsule.
Featuring a gold-sputtered, hand-tuned 34mm diaphragm, the S17 is loosely based on the original K67 capsule developed in 1960.
Far from creating another clone of a classic, however, Soyuz has further developed the design, modifying its assembly and tuning. The result, when paired with Soyuz’s original schematic, is unique – and uniquely musical.
Specifications
Type:
Tube condenser microphone
Capsules:
Two 34mm membranes (one gold sputtered)
Frequency Range:
20Hz / 20kHz
Polar Pattern:
Cardioid
Sensitivity:
40 mV/Pa
Impedance:
270 Ohms
SPL:
140 dB
Equivalent Noise:
20 dB Equivalent Noise - 20 dB (a-weighted)
Tube Type:
6ZH1P
Power:
Dedicated power supply - BP – 017
Size:
226mm length x 55mm diameter
Weight:
950g (single microphone)
Extras:
wooden oak suitcase, power supply unit with -20db pad, 6 pin cable, custom shock mount and hard mount, spare tube
Type:
FET condenser microphone
Capsules:
Two 34mm membranes (one gold sputtered)
Frequency Range:
20Hz / 20kHz
Polar Pattern:
Cardioid
Sensitivity:
38 mV/Pa
Impedance:
200 Ohms
SPL:
140 dB
Equivalent Noise:
18 dB (a-weighted)
Power:
48V Phantom power
Size:
226mm length x 55mm diameter
Weight:
930g (single microphone)
Extras:
wooden oak suitcase, -20db pad, custom shock mount and hard mount
